Custom Round 4-Bolt Intake Flange – Dust Extraction, Blower and Pump Adapter

Designer

Rapid3d4service

Designer relation

Ingen

Kategori

Tools

Licens

Creative Commons Attribution ShareAlike Creative Commons - Attribution - Share Alike

$ ↺ SA

Attribution påkrævet; afledte værker skal deles under kompatibel ShareAlike-licens.

Designer commercial

None

Først set

2026-09-14 19:50

Sidst set

2026-09-15 16:20

Tags

Ingen tags fundet

Beskrivelse

Create a custom round 4-bolt intake flange for dust-extraction systems, blower inlets, pump connections, suction hoses and ventilation projects. The model combines: A circular four-hole mounting flange A straight hose or pipe connection A smooth tapered transition A continuous internal flow channel Automatically calculated wall thicknesses and fillets Configure these dimensions online: Internal pipe diameter Pipe connection length Flange outside diameter Flange thickness Bolt-circle diameter Mounting-hole diameter A typical application is a dust-extraction connection mounted to a machine or filter enclosure. The flange is fastened with four bolts and a suitable gasket, while the flexible hose is pushed over the straight pipe connection and secured with a hose clamp. Configure your dimensions and generate the STL here: https://www.buildyour3d.com/en/product/parametric_round_intake_flange_v1 Please verify the dimensions, gasket, operating temperature, material, pressure and mechanical load before printing. This model is not intended for fuel, hot exhaust, drinking water, certified pressure systems or other safety-critical applications.
