Various parts for making an insect screen

Designer

Arnoud_Whizzbizz

Designer relation

Ingen

Kategori

Household > Bedroom

Licens

Creative Commons Attribution NonCommercial Creative Commons — Attribution — Noncommercial

$ ↺

Attribution påkrævet; kommerciel brug er ikke tilladt.

Designer commercial

None

Først set

2026-07-15 08:10

Sidst set

2026-07-19 08:10

Tags

grip hinge cornerpiece insectscreen

Beskrivelse

Various parts for the aluminum insect screen profile available at most hardware stores in the Netherlands (Europe). See the dimensions in the cross-section image. The wall thickness is 1 mm. The visible width of the frame is 25 mm. Print four corner pieces to make a square insect screen. The hinges are fitted with a 35 mm long piece of (spring) steel with a 4 mm diameter. It locks into place in one half and rotates freely in the other. The hinges can also be taken apart so that the screen can be removed. At the bottom, I mounted a handle and two metal plates for the magnetic latches.
