DIY Rock Tumbler

Designer

Gpack03

Designer relation

Ingen

Kategori

Electronics

Licens

Creative Commons Attribution ShareAlike Creative Commons - Attribution - Share Alike

$ ↺ SA

Attribution påkrævet; afledte værker skal deles under kompatibel ShareAlike-licens.

Designer commercial

None

Først set

2026-07-10 12:25

Sidst set

2026-07-10 17:33

Tags

3030 3030 extrusion aluminium 3030 aluminum aluminum extrusion DIY electronics electronics electronics enclosure motor motor mount pvc pipe rock tumbler rock tumbler frame rocks Timing Pulley tumbler tumblers

Beskrivelse

Custom Rock Tumbler (3D Printed + Aluminum Frame) This is a custom-built rock tumbler designed using a combination of 3D-printed components, aluminum extrusion, and off-the-shelf hardware. The goal of this project was to create a clean, modular, and efficient alternative to traditional DIY tumblers. The design uses a belt-driven shaft system with a geared DC motor, allowing for controlled speeds in the ideal 40–60 RPM tumbling range. A combination of printed wheels (PLA or TPU) supports the drum. The frame is built from standard aluminum extrusion, making the design. Check out my YouTube Video Build Tutorial! Coming soon:) See the "Material Cost Breakdown" PDF attached for the full BOM.
